SAVÖX SB-2274SGPLUS - High Voltage Brushless Steel-Geared High Speed/Torque Servo
The Savox SB-2274SG Plus High Voltage Brushless Digital Servo combines leading edge technology with super high 12 bit (4096) resolution.
Features:
- New: Soft Start
- High Voltage
- Unique steel gear train
- Brushless motor for smooth operation and efficiency
- Ideal for 1/10, 1/8 buggies, and large scale aircraft
Specifications:
- Torque @ 6V: 20kg/cm
- Torque @ 7.4V: 25kg/cm
- Torque @ 8.4V: 30kg/cm
- Speed @ 6V: 0.105 sec/60 deg
- Speed @ 7.4V: 0.08 sec/60 deg
- Speed @ 8.4V: 0.07 sec/60 deg
- Dimensions L x W x H: 40.3 x 20.2 x 38.7mm
- Weight: 69g
Technical Details:
- Operating Temperature: -10° to 50°C
- Running Current (no load): 180mA @6.0V, 220mA @7.4V
- Stall Current (at locked): 6000mA @6.0V, 7400mA @7.4V
- Idle Current: 5mA @6.0V, 5mA @7.4V
- Wire Length: 300 +/- 5mm
- Output Gear Spline: 25 Tooth
- Bearings: 2BB
- Operating Travel: 100° (1000 → 2000 µ second)
- Neutral Position: 1500 µ second
- Pulse Width Range: 800 → 2200 µ second
- Maximum Travel: Appx 130° (900 → 2100 µ second)
- Refresh Rate: 333 Hz
- Motor Type: Brushless
*NOTE: Certain combinations of receiver and ESC have been found to cause "Brown Out" issues when combined with Savox servos. An external BEC, or BEC stabilizing receiver capacitor may be needed for efficient, glitch free operation in low voltage electric applications.
