RC4WD D0031 King Off-Rd Piggyback Shocks/Faux Reservoir 100mm

Art.nr: D0031

769,- ~~799,-~~ -4%

Du vil motta en e-post så snart produktet er på lager!

En ukjent feil har oppstått. Prøve igjen

RC4WD

På lager: 2

Informasjon
Produsent

RC4WD King Off-Road Scale Piggyback Shocks w/Faux Reservoir (100mm)

These are the all new Licensed Scale Shocks to hit the market and are officially Licensed from King Off-Road Shocks. These new shocks feature a completely new design from the ground up and are built and ready to handle the rocks. Your scale build will never be the same once you bolt up a set of these awesome looking shocks!

Specifications:

Machined Billet Aluminum
King Logo on Faux Piggyback and Retainer Ring
Dual Spring Design
Hole to Hole (Compressed): 2.75in / 70mm
Hole to Hole (Uncompressed): 3.93in / 100mm
Overall Length: 4.28in / 108.9mm
Travel Length: 1.18in / 30mm
Shock Body OD: 0.39in / 10mm
Spring Body OD: 0.57in / 14.5mm
Shaft Diameter: 0.17in / 3.5mm
Weight: 0.9oz / 26g

Shown on Axial Wraith for example only (Not Included)

Shown installed on Traxxas TRX4 with 2mm Black Spacer with M3 Hole (10) (Z-S0600) and 3mm Black Spacer with M3 Hole (10) (Z-S0806) for example (Not Included)

Installed on our customer's truck:

What's Included:

2x RC4WD King Off-Road Scale Piggyback Shocks w/Faux Reservoir (100mm)

Replacement Parts:

Center Spring Retainer for King Offroad Shocks (Z-S0706)
Lower Spring Retainer for King Offroad Shocks (Z-S0707)
Replacement Shock Shafts for King Shocks (100mm) (Z-S0784)
Shock Cap for Top of King Offroad Shocks (Z-S0866)
Rebuild Kit for Scale King, ARB & Superlift Shocks (Z-S0788)

Optional Parts:

100mm King Scale Shock Spring Assortment (Z-S1117)
This product will fit the front of the Traxxas Telluride 4x4, but you will need 4x M3 x 14mm BHCS (Z-S0655)

Notes:

Use blue (medium) thread lock to the bottom shock shaft rod end before installing onto your vehicle to help keep it in place.
Fits Traxxas TRX-4, but will require both 2mm Black Spacer with M3 Hole (Z-S0600) and 3mm Black Spacer with M3 Hole (Z-S0806) Black Spacers with M3 Holes
When installing on Axial SCX10-3 please use a 5mm Black Spacer with M3 Hole (Z-S0821) on the shock tower.)

King Off-Road is a registered trademark of the King Off-Road Shock company. The King Off-Road logo is property of King Off-Road Shocks and used under license by RC4WD.
